Simple Temperature Control Oil Pressing

  Camellia oil is derived from the seed of the fruit of the camellia tree. The production process of camellia oil can be divided into: shelling, drying, crushing, steaming/roasting, oil extraction, filtration. Tea oil does not contain erucic acid, cholesterol. According to the test, unsaturated fatty acids in camellia oil are as high as 90%, oleic acid reaches 80-83%, linoleic acid reaches 7-13%, but the content of linolenic acid is very low.

  Camellia oil press can be physically pressed by screw oil press. The high instantaneous pressing temperature of the oil in the press chamber has an impact on both the oil and the cake. For example, the impurities of camellia oil are more and the color is darker, which reduces the refining rate of camellia oil. Therefore, the technology of spiral oil pressing requires that the tea seeds be husked.

The key process quality control points of high temperature pressing method are husking, steaming and pressing. In the husking process, after thousands of baked camellia seeds (moisture content of 12%14%), enter the camellia seed husking machine to break the shell, then carry out wind separation, kernel shell separation; In the steaming process, the water and temperature of camellia seeds should be adjusted, and the water content of camellia seeds should be controlled at about 3%, and the pressing temperature should reach 110~120°C; In the pressing process, through continuous physical pressing, the camellia oil is released uninterrupted from the press.

The advantages of mechanical pressing method are simple and flexible process, strong adaptability, low cost, less investment, and no solvent residue in pressed oil, but the oil yield of camellia seed is not high, because of the high content of reducing sugar, total sugar and starch in camellia seed kernel, Maillard reaction is easy to occur when pressing oil to deepen the color of the oil, thereby increasing the amount of active clay in the decolorization process. In addition, because the raw materials of the mechanical pressing method need to be steamed or baked heat treatment, the protein will be denatured, the comprehensive utilization value of the cake meal after oil extraction decreases, and the residual oil rate in the slag is high, and it still needs to be leached by solvent

Machine Parameter:

Details Picture:

Simple auto-temperature control oil press has both the continuation of the various advantages ZX series single oil press, but also combines the following key：

1.The screw shaft and main pressing cage is internally installed electric heating pipes which can preheat them at the same time. This way can absolutely save the preheating time.

2.The press is equipped with electrical control cabinet, which can always monitor the temperature inside pressing cage, thereby improving the reliability of heating and making the material a higher oil yield.

3.The machine's heating devices, not only make full use of high temperatures to achieve environmental protection, green energy requirements, but also improve the quality of crude oil；

4.Oil tray and cover made of stainless steel, more convenient to clean, so it become the first choice of small-medium enterprises and individual refineries preferred products.

Ruian Every Machinery (MCRAYONE) is located in Zhejiang province, China. Our annual production capacity of oil press machines and related machines is around 10,000 sets. These machines have sold to all over the world, such as South Africa, Nigeria, America, India and so on. Thanks to our experience in the oil press industry (more than 40 years ), we know the demands and best-selling models of each market, so we can provide the most suitable machines to our customers.

We have an experienced engineer team, a professional Research and Design department, and a perfect Quality Control System. All the parts are made by our own factory and the quality can be guaranteed. In addition, we provide a quality warranty for one year.

Our business involves in small-sized oil pressing series, oil engineering designing, equipment manufacturing and installing, project contracting, technical service and so on. Moreover, we have important partnerships with many large Chinese companies, such as China Oil and Food Import and Export Corporation. We are their designated foreign trade exporter and their supplier for small oil presses.

Our goal is to establish a long-term relationships with our customers, based on providing quality machines at a reasonable cost and maximize the customer returns with comprehensive service.

In the course of our company's decades of development, we have obtained multiple official certificates, such as :

• ISO-9001 international quality system certification
• CE certificate
• China's AAA credit enterprises
• Certification for honoring contracts and keeping promises
• Certificate of Integrity management demonstration unit
• Certificate of Quality Service Integrity Unit
• Enterprise Credit Rating Certificate

Our company has grown into one of the leading oil press manufacturers in China, and our popularity has spread abroad. We welcoming all kinds of orders.
